Name: MGL26400 - Square D - Molded Case Circuit Breaker
Brand: Schneider Electric
SKU: MGL26400
Price: 8459.99 CAD
Availability: InStock

MGL26400 - Square D 400 Amp 2 Pole 600 Volt Molded Case Circuit Breaker

Images are for reference only

In stock and ready to ship
Inventory on the way

Condition

New

Reconditioned

Quantity

Secure transaction

FREE & fast shipping on orders over $49

CSA approved with 1 year warranty

30 day returns

[{"id":40513539801197,"title":"New","option1":"New","option2":null,"option3":null,"sku":"MGL26400","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"MGL26400 - Square D - Molded Case Circuit Breaker - New","public_title":"New","options":["New"],"price":845999,"weight":13154,"compare_at_price":null,"inventory_management":"shopify","barcode":"785901507567","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":40755425575021,"title":"Reconditioned","option1":"Reconditioned","option2":null,"option3":null,"sku":"MGL26400_recon","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"MGL26400 - Square D - Molded Case Circuit Breaker - Reconditioned","public_title":"Reconditioned","options":["Reconditioned"],"price":789999,"weight":13154,"compare_at_price":845999,"inventory_management":"shopify","barcode":"785901507567","requires_selling_plan":false,"selling_plan_allocations":[],"quantity_rule":{"min":1,"max":null,"increment":1}}]

Returns are easy

You may return items within 30 days of delivery for a full refund.

View our return policy

FREE Shipping on orders over $49.

Canada Breakers offers one to five day delivery in Canada & United States. The variation depends on the warehouse location for the product(s).

Same Day Shipping

We strive to ship out your items within one business day.

In rare circumstances, Canada Breakers may reserve up to 5 business days to complete shipment. Feel free to contact us if your order is time sensitive.

Product Warranty - MGL26400 - Square D - Molded Case Circuit Breaker

All products, new and used, carry a 1-year warranty from Canada Breakers. All products sold by Canada Breakers are authentic and CSA approved.

Overview

Product Specifications - MGL26400 - Square D Powerpact Circuit Breaker

Part Number:

MGL26400
Manufacturer:

Schneider Electric / Square D
Family:

Powerpact
Pole:

2
Amp

400
Volt:

600
Phase:

1

Category:

Molded Case / 2-Pole
Connection:

Feed-Thru
Type:

MGL
Functions:

LI - Long-Time and Instantaneous
Protection:

Solid State
AIC Ratings:

35kA@480V

Dimensions

Dimensions (HxWxD):

12.86" x 8.27" x 8.05"
Weight:

29 lbs

Standards

Additional Details

Frame Type:

M-Frame
Trip Unit Technology:

Electronic, basic, ET 1.0,
Line Rated Current:

400 Amp
Mounting Mode:

Unit Mount Lug

Breaking Capacity Code:

G
Electrical Connection:

Lugs line / Lugs load
Continuous Current Rating:

80%
Control Type:

Operating Handle
AWG Gauge:

3 x AWG 3/0...3 x 500 kcmil aluminium/copper

Product Description - MGL26400 - Square D Powerpact Circuit Breaker

Schneider Electric,Square D, Powerpact, type MGL, 2P, 1PH, 400A, 600V, 35kA@480V, UL listed, high interrupting capacity, feed-thru, complete with basic non-interchangeable 1.0 trip, LI - Long-Time and Instantaneous trip functions and line & load side lug terminals, solid state electronic.

Documentation

Catalogue

Installation Instruction

Data Sheet

MGL26400 - Square D - Molded Case Circuit Breaker

Feed-Thru - 400 Amp - 2 Pole - 600 Volt

MGL26400 - Square D - Molded Case Circuit Breaker

Feed-Thru - 400 Amp - 2 Pole - 600 Volt
